Professional Pass Box/Pass Through Window Supplier

Professional Pass Box/Pass Through Window Supplier

Professional Pass Box/Pass Through Window Supplier

Lead_Time
1 - 1(Sheets):7(days),2 - 10(Sheets):12(days),11 - 20(Sheets):15(days),>20(Sheets):Negotiable(days)
shipping
Sea freight
Customization
Customized packaging (Min. Order: 1 Sheets),Customized logo (Min. Order: 1 Sheets),Graphic customization (Min. Order: 1 Sheets)
Model Number
SP-PB
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Overview
Quick Details
Condition:New
Applicable Industries:Hotels, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Retail, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops
Weight (KG):80
Showroom Location:Canada, Turkey, United Kingdom, United States, Italy, Germany, Philippines, Saudi Arabia, Pakistan, India, Mexico, Russia, Spain, Argentina, South Korea, Chile, UAE, Colombia, South Africa, Ukraine, Nigeria, Uzbekistan, Japan, Malaysia, Australia
Video outgoing-inspection:Provided
Machinery Test Report:Provided
Marketing Type:New Product 2022
Warranty of core components:1 Year
Core Components:Engine, Bearing, Motor
Place of Origin:Jiangsu, China
Brand Name:SUZHOU PHARMA MACHINERY
Warranty:1 Year
Size:Customized Size
Type:Static/Dynamic
Material:Stainless Seel 304
Product name:Pass box/Transfer Window
Wind speed:0.36~0.54m/s(Adjustable)
Application:Clean room
Certifcation:CE Certification
Clean time:1-99s(Adjustable)
lnterlock:Mechanical Interlock/Electronic Interlock
Noise:55~63dB
Video Description
Product Description

Pass box is one of the cleanroom systems, which is used to transfer materials from one side to other side through controlled environment in order to avoid airborne cross contamination.

As the name states itself, the primary and only work of a pass box is
to pass material from one side to other without raising contamination concern and if any particulate matter presents on the material surface, it swipes away during the operation. Interlocking door mechanism is the prime feature of a pass box, when door at one side is open the door at other side remains closed.

It is popular with other names such as cleanroom pass through, clean
transfer window and transfer hatch; in addition, it is widely used in microbiology laboratories in food, pharmaceutical and chemical industries.

Power
110V, 220V
Size
600mm*600mm*600mm/Customized
Product name
Pass box/Transfer Window
Material
Stainless Seel 304
Application
Clean room
lnterlock
Mechanical lnterlock/electronic in
Type
Static/Dynamic
Certifcation
CE Certification
Noise
55~63dB
Clean time
1-99s(Adjustable)
Wind speed
0.36~0.54m/s(Adjustable)

Air shower type electronic interlock transfer window

Specification: PB-3 PB-6 External dimensions (L×W×H mm) 980×700×1800 Internal dimensions (L×W×H mm) 660×700×600 Wind speed: 25m/s or more Number of nozzles: 4 Air shower cycle: 15s Door interlock mode: mechanical interlock, electronic interlock Cabinet material: high-quality cold-rolled steel plate, surface electrostatic spray treatment, matte white (various colors can be customized) Inner wall material: stainless steel plate Power supply: 380V 50HZ three-phase 380V 50HZ three-phase Power: 0.75KW 0.75KW

Electronic interlocking transfer window

Specification: PB-1 PB-2

External dimensions (L×W×H mm) 785×600×690

Internal dimensions (L×W×H mm) 600×600×600

Door interlockmode: electronic interlock, mechanical interlock

Cabinet material: high-quality cold-rolled steel plate, surface electrostaticspray treatment, matte white (various colors can be customized)

Inner wall material: stainless steel plate
Packing & Delivery
Company Profile
FAQ
1.Who Are We?
Our company is headquartered in Suzhou City, Jiangsu Province, China. The company has 10-50 employees. The office area is 700 square meters. The factory covers an area of 3,000 square meters and there are 2 large storage warehouses. Since 2016,our company has completed more than 500 clean room projects worldwide. We have a wealth of transportation experience and a professional team. Every year, an average of more than 50 40-foot-tall containers are shipped to countries around the world. We are a very professional supplier and manufacturer in China.
2.How Can We Guarantee Quality?
Always a Pre-Production Sample Before Mass Production;Always Final Inspection Before Shipment;
3.What Can You Buy From Us?
Clean Room,Cleanroom Equipments,Pharmaceutical Machine,Machine Parts,Supercritical Co2 Extractor,Dust particle counter
4.Why Should You Buy From Us Not From Other Suppliers?
Our Engineer Has More Than 15 Years Experience On Pharmaceutical Machine And Clean Room Project; Our Sales Team Has Been Professional Trained On Technic And Service; All The Product Will Be Given Twice Time Guarantee Period As Quality Confidence And Trust.

The product is able to help increase the safety of the working environment. By using this product, workers are not prone to injury. Most industries are banking on this product. It is designed to fit continuous adjustments during the ongoing production, aiming to increase efficiency and reduce costs.
