Machine Model : NJP-1200
Filling dosage : Powder,Pellet,Tablet
Capsule Size : Suitable for filling capsule size 00#-5# Supro/safety capsule size: A-E
Max. Output : 72000 Capsules/H
Power Supply : 380V 50Hz 6.82kw
Noise : <78dBA
Dimension : 1500×1040×1970mm
Net weight : 1200Kg
This machine is designed to meet the Volume-produce on the base of model NJP-1200 automatic capsule filling machine.
1. Velocity modulation and PLC control.
2. Easy to operate and install.
3. Completely meet the GMP requirements.
4. Meet CE Quality
Main Features: The working station cam runs under the good lubricating condition, and maintains the inner lubrication of cam slot to a full extent, increasing the pressure pulverization oil pump, thus extends the operation life of the spare parts. It is controlled by the computer, has a stepless timing with the frequency-conversion, the numeral showing makes an easy operation and clear appearance. |
Machine Model | NJP-1200 | NJP-1500 | NJP-2000 | NJP-2200 | NJP3200 |
Filling dosage | Powder,Pellet,Tablet | Powder,Pellet,Tablet | Powder,Pellet,Tablet | Powder,Pellet,Tablet | Powder,Pellet,Tablet |
Capsule Size | Suitable for filling capsule size 00#-5# Supro/safety capsule size: A-E | Suitable for filling capsule size 00#-5# Supro/safety capsule size: A-E | Suitable for filling capsule size 00#-5# Supro/safety capsule size: A-E | Suitable for filling capsule size 00#-5# Supro/safety capsule size: A-E | Suitable for filling capsule size 00#-5# Supro/safety capsule size: A-E |
Max. Output | 72000 Capsules/H | 90000 Capsules/H | 120000 Capsules/H | 132000 Capsules/H | 192000 Capsules/H |
Power Supply | 380V 50Hz 6.82kw | 380V 50Hz 6.82kw | 380V 50Hz 6.82kw | 380V 50Hz 6.82kw | 380V 50Hz 6.82kw |
Noise | <78dBA | <78dBA | <78dBA | <78dBA | <78dBA |
Dimension | 1500×1040×1970mm | 1500×1040×1970mm | 1150×1050×1970mm | 1200x1070x2100 | 1420x1180x2150 |
Net weight | 1200Kg | 1300kg | 1300kg | 1500kg | 2000kg |
