Oem Tablet Machine Tdp 6mm Tdp0 Punch And Die For Sale-PHARMA

Customize die:available(send us logo and TDP)

day for custom:about 15-30days.

We also have candy press die in different designs,if you need it you can contact with us to know more designs.

We are able to create deep and intricate designs on a wide range of 3D shapes and sizes.

This set is in stock and available for immediate dispatch. We have a large selection of candy press dies for sale but if you

require custom candy molds, custom TDP punch dies or Rotary candy Press machinery tooling then please get in touch to discuss your ideas. If needed, our experts will work with you on the design so that it is correct before the manufacturing process begins. We aim to reply with a quote within 3 hours where possible.

We are able to have any punch die set manufactured to your exact specifications for any candy press machine. If you like the look of this stamp but would prefer it in a different size for your TDP-0, TDP-1.5, TDP-5, TDP-6, TDP-6s, ZP-5 or ZP-9 Zp15 Zp19 Zp33 Zp41 machine then let us know and we will be happy to manufacture to your requirements. We are experts in manufacturing to order for any candy press machine.

Available for immediate dispatch

We ship worldwide with an average delivery time of just 3 working days

1 full set = 1 top punch + 1 bottom punch + 1 centre ring die

Characteristics 1. It is made of carbon steel, bearing steel and chrome 12 2. Digital machining center precision manufacturing, in line with IPT standards 3. Corrosion resistance, impact resistance, wear resistance, high temperature resistance and long service life 4. Interchangeability 100% (no matter round or special mold)

Tablets are a common dosage form in medicinal preparations because of their convenience to take, and the die is an indispensable accessory on the tablet press of commonly used tablet equipment. It is also a very important task to correctly select the appropriate die after the tablet press is purchased. In daily life, many tablet pharmaceutical factories cannot use the tablet press normally due to improper die selection. In order to enable the users of the pharmaceutical factory to better order the appropriate die, this article will introduce some details. At the same time, it is recommended that the user of the pharmaceutical factory should have a full discussion with the die manufacturer first to reduce possible problems during production.

 Due to the characteristics of track design and processing technology, it is recommended that users must purchase products from the same factory for tablet press and die, and do not frequently change mold manufacturers, but choose factories with strong strength and good processing accuracy. Don't blindly pursue cheap and buy inferior dies, which will eventually damage the tablet press.

 Selection of tablet type: The correct selection of tablet type is the first step to the success of a tablet die. For example, chewable tablets require high hardness and are easy to chew. Most of them use bevel-edged flat tablets; those that require film coating can choose shallow-concave tablets. Because there are no binders and lubricants in the raw materials of Chinese tablets, it requires high pressure when compressing tablets, and the tablet shape is preferably shallow. For tablets with high sugar content, the design of the tablet shape is preferably shallow or flat. The middle mold can use alloy steel or hard alloy. The deep-concave sheet die is easy to damage, so use it as little as possible.

The main contents are cleaning, lubrication and inspection.

 A. Maintenance during mold installation:

      1.The upper and lower surfaces of the mold should be cleaned before installing the mold to ensure that the mold mounting surface and the working table of the press will not be compressed and damage the parallelism of the upper and lower mounting surfaces of the mold in production;

      2.After the mold is installed, open the mold and clean all parts of the mold, especially the guide mechanism. For the surface part of the mold, its surface should be cleaned to ensure the quality of the parts;

B. Maintenance in production:

      1.Oil the corresponding parts of the mould regularly during production. Such as: the pressing ring and fillet of the drawing die; the knife edge of the trimming die; the flanging knife block, etc;

      2.Clean up the small hole waste channel of trimming and punching die regularly.

C. Maintenance after production:

      1. After the end of production, the mold should be checked comprehensively;

      2. Clean the mold completely to ensure the cleanliness of the mold;

      3. Clean up the waste in the mould to ensure that there is no waste in the waste box;

      4. If it is used for a long time, spray antirust oil after cleaning. If it isnot used for a long time, put it in diesel after cleaning

	TDP single punch tablet press machine in stock This machine is designed for pressing round tablets from various granular materials, applicable to be used for research and development and to small scale production. As its feature, it is an all desk-top continuous press driven by motor or man power. Only one set of punch and die is mounted. The depth of the filling material and the thickness of the tablets can be adjusted.
zp12 rotary tablet press machine New type rotary tablet press gives you better quality and price, automatic tablet press for pressing granular raw materials into. This machine is a single press type, continuous automatic tablet press for pressing granular raw materials into tablets. It is mainly used in pharmaceutical industry and also the chemical, food, electronic, plastic and metallurgical industries.
	Tdp Tablet press punch die set This mold could be used in Manual tablet press machine,TDP-0,TDP-1.5,TDP-5,TDP-6;Rotary tablet press (ZP-5.ZP-7 ZP-9 ZP-10 ZP-12 ZP-15 ZP-19 ZP-23 ZP-29 ZP-33 Etc） Tablet press punches, die, tablet press tooling and tablet press mould.
8mm pill press punch die This mold could be used in Manual tablet press machine,TDP-0,TDP-1.5,TDP-5,TDP-6;Rotary tablet press (ZP-5.ZP-7 ZP-9 ZP-10 ZP-12 ZP-15 ZP-19 ZP-23 ZP-29 ZP-33 Etc） We apply the newest CAD/CAM technology and advanced heat treatment technology and scientific measuring means to machine various kinds of punch and die with high grade bearing steel for tool.
