1.Frame Structure: The unit adopts the full aluminum alloy anti-cold-bridge frame structure. Every angle of the frame is connected by the aluminum alloy structure component with the excellent strength, light weight, anti-corrosion capability and beautiful appearance.
2.Panel structure: The unit adopts the panel of the double-layer structure: inside and outside. The inside panel is the zinc-plated steel plate and producing foam by the middle polyurethane, and its features are: good strength, good anti-cold-bridge capability, good noise of noise separation, and it is suitable for the places with high requirements of air quality.
Focus On Professional Factory Cleanroom Workshop Project And Machinery Only.
Phone:+8618241958031 Email: pharma@sz-pharma.com
Modular Pharmaceutical Cleaning Room AHU Unit
5.0
shipping:
Sea freight
Power:
[{'sku_name': '12.5KW', 'sku_img': None, 'sku_id': '200001194:280098874;'}]
Model Number:
[{'sku_name': 'PH-AHU-1', 'sku_img': None, 'sku_id': '3:-1;'}]
Lead_Time:
1 - 1(Sets):35(days),2 - 5(Sets):55(days),>5(Sets):Negotiable(days)
Customization:
Customized logo (Min. Order: 1 Sets),Customized packaging (Min. Order: 1 Sets),Graphic customization (Min. Order: 1 Sets)
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Overview
Quick Details
Applicable Industries:Manufacturing Plant
Condition:New
Type:Air Handling Unit
Place of Origin:Jiangsu, China
Brand Name:SUZHOU PHARMA MACHINERY
Operating Voltage:380/400 VAC
Mounting:Ceiling Mount, Floor Standing or Roof
Warranty:2 years
Dimension(L*W*H):customized size, Customized size
Key Selling Points:Automatic
Airflow:800-10000m3/h, 800-10000m3/h
Machinery Test Report:Provided
Video outgoing-inspection:Provided
Warranty of core components:1 Year
Core Components:Pressure vessel, Motor, Bearing, PLC, Gearbox
Weight (KG):800 KG
Noise:50-95dB(A)
Fan type:Direct driven or belt driven
Outer Panel thickness:25/40/50mm
Panel type:Double skin
Temperature/Humidifer:Customized
Intelligent control:PLC or Button
Dehumidifier:Optional
Video Description
Product Description
An air handling unit, commonly called an AHU, is the composition of elements mounted in large, accessible box-shaped units called modules, which house the appropriate ventilation requirements for purifying, air-conditioning or renewing the indoor air in a building or premises.
They are usually installed on the roof of buildings and, through ducts, the air is circulated to reach each of the rooms in the
building in question.
They are usually installed on the roof of buildings and, through ducts, the air is circulated to reach each of the rooms in the
building in question.
In addition to managing the proper ventilation of the interior with outside air, the AHU performs other functions:
A：Filtration and control of the quality of the air that will reach the interior, thanks to the air purification filters, and depending on the retention of these filters, the air will be clean.
B：Control of the air temperature that regulates the air conditioning system in cold or hot, so that the thermal sensation in the interior is the desired one.
C：Relative humidity monitoring for greater indoor comfort.
3.Wind Machine and Engine: The unit adopts the acentric wind machine of double ways of putting in wind. The wind machine passes the action and stability test, and the operation is stable with little noise. The bearing of the wind machine adopts the imported bearing and the engine adopts the low-noise motor.
4.Heat Exchanger: The turn-up heat exchanger adopts the structure of the high quality copper pipe passing through the aluminum piece. It is the optional design, and its capability of heat exchanging is good with little wind block and water block.
5.The filter unit adopts the high quality plate type plate with primary filter. It has little wind block and it can be cleaned for many times.
6.Water Concentration Plate: The water concentration plate adopts the new dry type structure with the plastic coat on top to ensure the smooth discharge and avoid the problem of water leakage.
7.The functions of heating, increasing humidity and filter with medium effect can be added according to the requirements of the clients.
Specification
Airflow | 800-10000m3/h |
Pressure | 150-500PA |
Cooling/Heating Capacity | 12/19 KW |
Water Flow | 10KPA |
Inlet/Outlet | DN32 |
Power | 2.2KW |
Temperature/Humidity | Customized |
Cases
Packing & Delivery
Drawing
Company Profile
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory. Q: What is the MOQ? A: 1 set,if you order more ,the labor cost and delivery will be cheaper.
Q: How long is your delivery time ?
A: Generally it is 15-20 working days if the goods are in stock;or it is 30-35 working days if the goods are not in stock,it is according to quantity.
Q:Can I get special design and function?
A:Yes, We are very pleased to be able to provide you with new designs, or to manufacture according to your drawings.
Q:How can you guarantee high level manufacturing process and installation?
A:We are professional suppliers for more than 13 years.We have the best designers,engineers.We will design and manufacture according to the standards of the cleanrooms. We have full experience installation workers, they can make perfect buildings with professional skills.
Q:What industry of clean room you can supply?
A:Hospital, laboratory, pharmaceutical, medical, electronic, biological, food and beverage, cosmetics industry,etc. Q:What
products does your company specialized in? A:Our company specialized in clean room turnkey projects, prefab houses, and air clean equipments.
A:Hospital, laboratory, pharmaceutical, medical, electronic, biological, food and beverage, cosmetics industry,etc. Q:What
products does your company specialized in? A:Our company specialized in clean room turnkey projects, prefab houses, and air clean equipments.
