Warranty:1 year
Product height:10-350mm
Product diameter: 20-150mm
Conveying direction:left-right, right-left
Feature: Easy to Operate
Suitable for:Bottles
Max label specification:360 mm 76 mm
Label length: 10-250mm
Label height: 15-180 mm
The lamination conveyor adopts a synchronous belt structure to avoid belt slippage and unstable labeling during the lamination process. The synchronous belt adopts thick and wear-resistant high-quality sponge to avoid excessive extrusion and damage to the labeling products. Can carry greater resistance.
Characteristics ◆Using a new type of elastic pressure topping mechanism to ensure stable product delivery and effectively eliminate the inherent error of bottle height; ◆The labeling is accurate and stable. It adopts PLC+subdivision stepping motor to drive the label delivery, and the label delivery is accurate; the cam brake mechanism is adopted to ensure uniform tension to ensure the tension of the label, reduce label breakage, and ensure accurate label detection; With detour correction mechanism, it can prevent the label from shifting left and right, and ensure the accuracy of the label; ◆Powerful functions, color touch screen control, Chinese and English optional operation interface, convenient and intuitive, powerful data memory function, can store 50 sets of labeling parameters, production counting function, power saving function, production number setting prompt function, parameter setting protection Function, convenient for production management, one-click switching of labeling for different products, no need to repeatedly debug, simple and fast; and has a complete fault prompt and help function; |
Applicable product range | Diameter: 20-150mm Height: 10-350mm |
Applicable label range | Height: 15-180 mm Length: 10-250mm |
Operating power(kw) | 0.18 |
Machine Model | SH-300 |
Drum Diameter | 300mm |
Max material load capacity | 20-30 lbs |
Max Rotating Speed | 1400r/min |
Motor Power | 1kw |
Machine weight | 300kg |
Machine Dimension | 580*550*600mm |
