Industrial Durable AHU Unit-PHARMA

Related Products

HVAC AHU Air Conditioning Unit

Better AHU Unit In Iso7 Standard Clean Room

Ceiling HVAC System Direct Expansion Purifying Cabinet

Plc Intelligent Control Clean Room AHU Unit

Product Information
Company Profile

Overview

Quick Details

Applicable Industries:Manufacturing Plant

Condition:New

Type:Air Handling Unit

Place of Origin:Jiangsu, China

Brand Name:SUZHOU PHARMA MACHINERY

Operating Voltage:380/400 VAC

Mounting:Ceiling Mount, Floor Standing or Roof

Warranty:2 years

Dimension(L*W*H):customized size, Customized size

Key Selling Points:Automatic

Airflow:800-10000m3/h, 800-10000m3/h

Machinery Test Report:Provided

Video outgoing-inspection:Provided

Warranty of core components:1 Year

Core Components:Pressure vessel, Motor, Bearing, PLC, Gearbox

Weight (KG):800 KG

Fan type:Direct driven or belt driven

Noise:50-95dB(A)

Outer Panel thickness:25/40/50mm

Panel type:Double skin

Temperature/Humidifer:Customized

Intelligent control:PLC or Button

Dehumidifier:Optional

Video Description

Product Description

An air handling unit, commonly called an AHU, is the composition of elements mounted in large, accessible box-shaped units called modules, which house the appropriate ventilation requirements for purifying, air-conditioning or renewing the indoor air in a building or premises.
They are usually installed on the roof of buildings and, through ducts, the air is circulated to reach each of the rooms in the
building in question.

In addition to managing the proper ventilation of the interior with outside air, the AHU performs other functions:

A：Filtration and control of the quality of the air that will reach the interior, thanks to the air purification filters, and depending on the retention of these filters, the air will be clean.

B：Control of the air temperature that regulates the air conditioning system in cold or hot, so that the thermal sensation in the interior is the desired one.

C：Relative humidity monitoring for greater indoor comfort.

product-Industrial Durable AHU Unit-PHARMA-img

1.Frame Structure: The unit adopts the full aluminum alloy anti-cold-bridge frame structure. Every angle of the frame is connected by the aluminum alloy structure component with the excellent strength, light weight, anti-corrosion capability and beautiful appearance. 2.Panel structure: The unit adopts the panel of the double-layer structure: inside and outside. The inside panel is the zinc-plated steel plate and producing foam by the middle polyurethane, and its features are: good strength, good anti-cold-bridge capability, good noise of noise separation, and it is suitable for the places with high requirements of air quality.

product-Industrial Durable AHU Unit-PHARMA-img-1

3.Wind Machine and Engine: The unit adopts the acentric wind machine of double ways of putting in wind. The wind machine passes the action and stability test, and the operation is stable with little noise. The bearing of the wind machine adopts the imported bearing and the engine adopts the low-noise motor.

4.Heat Exchanger: The turn-up heat exchanger adopts the structure of the high quality copper pipe passing through the aluminum piece. It is the optional design, and its capability of heat exchanging is good with little wind block and water block.

5.The filter unit adopts the high quality plate type plate with primary filter. It has little wind block and it can be cleaned for many times.

6.Water Concentration Plate: The water concentration plate adopts the new dry type structure with the plastic coat on top to ensure the smooth discharge and avoid the problem of water leakage.

7.The functions of heating, increasing humidity and filter with medium effect can be added according to the requirements of the clients.

Specification

Airflow	800-10000m3/h
Pressure	150-500PA
Cooling/Heating Capacity	12/19 KW
Water Flow	10KPA
Inlet/Outlet	DN32
Power	2.2KW
Temperature/Humidity	Customized

Cases

product-Industrial Durable AHU Unit-PHARMA-img-2

Packing & Delivery

Drawing

product-Industrial Durable AHU Unit-PHARMA-img-3

Company Profile

product-Industrial Durable AHU Unit-PHARMA-img-4

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory. Q: What is the MOQ? A: 1 set,if you order more ,the labor cost and delivery will be cheaper.

Q: How long is your delivery time ?

A: Generally it is 15-20 working days if the goods are in stock;or it is 30-35 working days if the goods are not in stock,it is according to quantity.

Q:Can I get special design and function?

A:Yes, We are very pleased to be able to provide you with new designs, or to manufacture according to your drawings.

Q:How can you guarantee high level manufacturing process and installation?

A:We are professional suppliers for more than 13 years.We have the best designers,engineers.We will design and manufacture according to the standards of the cleanrooms. We have full experience installation workers, they can make perfect buildings with professional skills.

Q:What industry of clean room you can supply?
A:Hospital, laboratory, pharmaceutical, medical, electronic, biological, food and beverage, cosmetics industry,etc. Q:What
products does your company specialized in? A:Our company specialized in clean room turnkey projects, prefab houses, and air clean equipments.

Through fully mature quality test, the quality of our Clean Room can be guaranteed. Before shipment, SUZHOU PHARMA MACHINERY CO.,LTD. will conduct various types of tests to check quality of Clean Room.
