Industrial Automatic PVC Rolling Standard High Speed Door

Industrial Automatic PVC Rolling Standard High Speed Door

Industrial Automatic PVC Rolling Standard High Speed Door

Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:

-High speed door applies to external and internal door of workplace, such as food, medicine, electronic, automobile, logistics and machine. This kind of possessess good wind resistance and heat insulation.



-High speed door is stable, high speed, energy saving, eco-environment, sand resistance, insect resistance, easy change and clean.



-In order to meet the demand of customer, the door can be opened by hand control, radar control, geomagnetic control, remote control



PartsConfiguration
Door sizeW :1250-4000mm
H:1500-4000mm
Control Unit system1/ IP54
2/LED Screen
  The Engineer visual man-machine dialogue window indicates working status which is easy during the maintenance. LED screen provides full information       and enables Intelligent operation,rapidfeedback,user-friendly.
3/ Encode
 Full range absolute limit technology, position close-loop control, multi-turn absolute value encoder

Working temperature-10ºC~50ºC
Anti-wind11m/s
Power380V  0.75-1.5KW
OperationStandard one button control box including emergency control ,optional radar /loop induction/pull rope/remote controller etc.
BufferingFrequency conversion control system not only ensures stable door operation but also enable the protection of  the Reduction gear and the brake pads ,especially the Reduction gear
Open-close speedOpen Speed: 0.8-1.2m/S Close0.8m/S
Curtain materialOrigin :France thickness 1 mm
Inflaming retarding B1
Transparent PVC strips thickness 1.2-1.5mm
Frame materialGalvanize
SealingDouble sealing of the track, rubber bottom
Safety1/Infrared safety sensor:
Infrared safety sensor is installed on both sides of the door frame(12 lights or light ice height 600-1800mm) .It makes the door keep open when there is object under the door. If there is object moving during the door closing , it makes the door fully open until no object and closed then.
2/Bottom safety sensor(remote control):
It makes the door bounce immediately to the fully open position if there is object under during the door closing which protects the object under or perosonnel from injury .



product-PHARMA-img-1product-PHARMA-img-1

SUZHOU PHARMA MACHINERY CO.,LTD. is committed into providing the best customer service. SUZHOU PHARMA MACHINERY CO.,LTD. ensures that the products are flawless and trouble-free before leaving the factory and give customers better quality assurance.
SUZHOU PHARMA MACHINERY CO.,LTD. is committed to providing the highest level of service for you. Our friendly and customer-focused employees are always pleased to help you with any questions you might have.
