Dynamic Pass Box Static Cleanroom Equipment Pass through box Manufacturer

Dynamic Pass Box Static Cleanroom Equipment Pass through box Manufacturer

Brand name:
PHARMA CLEAN
Original:
Suzhou, China
Payment:
T/T; Cash; Alibaba trade assurance
Delivery Time:
7-20 days, depending on the quantity
Supply Ability:
50-100 Sets/per month
Start Port:
Shanghai
Packing Details:
Carton packing,metal frame;plywood case
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
  • After Warranty Service: Video technical support, Online support, Field maintenance and repair service

  • Used: GMP clean room; Changing Room: Clean Booth; Hospital: Laboratory; Food workshop

  • Certification: CE ISO GMP

  • Name: Dehumidification

  • Door: 5mm Glass


product-PHARMA-Stainless Steel Pass Box Cleanroom Pass Through Box-img


Limit Discounts

Limit Discounts


product-PHARMA-img


Description

Description

pass box in pharma is an essential component of cleanroom systems. It is designed to transfer materials safely from one area to another, while maintaining a controlled environment and preventing airborne cross contamination. This is especially important in the pharmaceutical manufacturing industry, where specific materials may need to be transferred between areas with different levels of cleanliness. Stainless steel pass boxes come in two types - static and dynamic - and the design depends on the specific needs of the user. The main purpose of a pass box cleanroom is to facilitate transfer without introducing contaminants, and any particles on the surface of the material are removed during the process. These cleanroom boxes feature an interlocking door mechanism, ensuring that only one side can be open at a time. They are also known as cleanroom pass throughs, clean transfer windows, and transfer hatches, and are commonly used in microbiology laboratories within food, pharmaceutical, and chemical industries.


Pass-through boxes, commonly referred to as pass-through chambers, also known as pass through boxes and windows, provide a secure means of transferring parts and equipment between a cleanroom and an adjoining area. These pass through box clean room systems are essential for minimizing contamination in highly regulated life science environments. Specifically designed for medical and pharmaceutical spaces, these pass thru windows ensure the safe and efficient transfer of equipment, parts, and specimens from a cleanroom to a standard room.


Advantages of cleanroom pass boxes:

1. Easy to clean

Choosing a passthrough box with flat surfaces is much easier to clean because there is only a flat surface to be wiped, saving time and making it easier to maintain. The material of the cover should also be considered since it should not react with any of the chemicals present in the cleaning products.


2.Easy to integrate

System independent cleanroom pass boxes fit into any wall systems. Pharma's range of cleanroom pass boxes work with any structure, including sandwich panels and gypsum boards.


3. Air pressure drain

Request an air pressure drain to prevent overpressure and constant inflating. This tool will help keep the air pressure under control and maximise safety.


4. Advanced air tightness

Precise closing is critical when transferring material into the cleanroom. An aluminum profile system can guarantee the perfect air tightness for cleanrooms. Pharma pass boxes are equipped with premium EPDM gaskets.

product-Dynamic Pass Box Static Cleanroom Equipment Pass through box Manufacturer-PHARMA-img
Characteristics of pass through box clean room

The internal circular plate chamfering processing, no dead angle.

Embedded ultraviolet germicidal lamp on top.

Double hollow toughened glass observation window.

Two-door for large angle square window.



The pass thru box is a crucial element for product transfers in cleanrooms. Despite its straightforward design, it plays a vital role in maintaining the cleanroom's high level of cleanliness. By limiting the introduction of outside air into the clean zone, the pass box helps protect against cross-contamination. This is achieved through the use of either a mechanical or electrical interlock system, preventing both doors from being opened simultaneously.



A Cleanroom Pass Thru Helps To Eliminate The Risk Of Contamination, Allowing modular cleanroom manufacturers To Adhere To Industry Quality Standards. Several Industries That Commonly Utilize Pass Thrus Include:Medical, Pharmaceutical, Food Processing, Aerospace, Computers & Consumer Electronics.



product-PHARMA-img
product-PHARMA-img

product-Stainless Steel Pass Box Cleanroom Pass Through Box-PHARMA-img

Technical Parameters

Technical Parameters


TYPEStatic Pass BoxDynamic Pass Box
ModelSP-S01SP-S02SP-S03SP-D01SP-D02SP-D03
External dimension W×D×H(mm)660*500*580760*600*680860*700*780660*500*1400500*500*500600*600*600
Internal DimensionsW×D×H(mm)500*500*500600*600*600700*700*700500*500*500600*600*600700*700*700
MaterialSUS304 stainless steel; Pre-painted cold work steel sheet

InterlockElectronic; mechanical
UV Lamp30W*1
HEPA FILTER/Efficiency≥ 99.999% at 0.3um
AIR SPEED/
0.36~0.54m/s

Installation

Installation


product-PHARMA-Stainless Steel Pass Box Cleanroom Pass Through Box-img-1

product-PHARMA-img-1


product-PHARMA-img-1


product-PHARMA-img-1


product-PHARMA-img-1

product-Stainless Steel Pass Box Cleanroom Pass Through Box-PHARMA-img-1

product-PHARMA-Stainless Steel Pass Box Cleanroom Pass Through Box-img-2


product-PHARMA-img-2
