Aseptic sterility isolator system medicalsterilization system
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障



GMP aseptic sterility isolator system for labrotary/clean room





Production description



A sterile isolator is an effective way to reduce the risk of false positives in a sterile test. A sterile test isolator can be placed in a Class C or D environment, resulting in a significant reduction in the QC laboratory environment and a simplified Of the clothes and other environments.





Application



Uses: sterile detection, positive bacteria detection, high sensitivity, high activity of the material sampling, weighing, packaging, etc., on the material and the operator double protection.







Specifications





1. Stainless steel and tempered glass composed of hard wall structure, the internal environment for the dynamic A-level;

2. Use gloves to operate, gloves optional thickening resistant to damage or thin style;

3. Use H14-class high efficiency filter, through the PAO scan leak test;

4. System reserved for hydrogen peroxide (VHP) generator interface and valves, optional hydrogen peroxide steam generator for high levels of sterilization, hydrogen peroxide on the separator air and exposed surface can reach 106 spores Off effect;

5. Through a variety of ways, such as the air chamber, with the RTP system, such as the delivery compartment to achieve the safe entry and exit of goods;

6. Built-in power supply can be installed in the isolator, can also be installed with a valve of compressed air connector and cleaning water connector for water and intake;

7. System with Siemens logic controller (PLC) for fully automated control of pressure, air volume, and with loss of pressure alarm function;

8. With casters and locks, removable, fixed.





Detail show



product-PHARMA-img



product-PHARMA-img



product-PHARMA-Aseptic sterility isolator system medicalsterilization system-img



Parameters



Power Supply:AC220-380±38V/50Hz Max.Power Consumption: 30000W-4000W
Touch Screen Size :SIEMENS 7” Chamber Pressure Range :From -80Pa to+80Pa
Airflow Direction : Laminar flow RH Accuracy :0.10%
Temp.Accuracy:0.1℃ Pressure Accuracy :0.1Pa
Velocity : 0.36 -0.54m/s Chamber Integrity : Comply with ENISO14644-7
Applications :Sterility test ,sampling ,weighting ,dispense for the toxic and high sensitized drugs.





product-PHARMA-img-1

This product can turn out thousands of identical outcomes. Production has thus been standardized. Only this kind of product is capable of mass production. This product is able to help the worker in performing his or her duties in a better way than by hands.
SUZHOU PHARMA MACHINERY CO.,LTD. is committed to providing the highest level of service for you. Our friendly and customer-focused employees are always pleased to help you with any questions you might have.
