PHARMA laboratory furniture effectively for electronics factory
After Warranty Service: Video technical support, Online support, Field maintenance and repair service
Certification: CE ISO GMP
Name: Fume Hood
Size: 1500*850*2350mm or customized size
Used: Clean room
Limit Discounts
Description
Laboratory ventilation is an indispensable part of in the design of laboratory. In order to make the laboratory staff don't inhale or pharynx into some unknown toxic and can cause or toxicity of chemicals and organisms, the laboratory should have good ventilation. To prevent some of the steam, gas and particles (smoke, soot, dust and air suspension) absorption of pollutants must be used fume hoods and ventilation hood or local ventilation method to remove.
Local exhaust is a kind of local ventilation way to remove pollutants directly from the source of pollutants.One side of the fume hood is completely open, and the operator works in the fume hood, mainly used for painting large parts, powder bagging, etc |
Technical Parameters
| Item Name | Fume Hood |
| Size: | 1500*850*2350mm or customized size |
| Types: | Bench-top Fume Hood ; Walk-In Fume Hood ;PP Fume Hood;SS Fume Hood; Steel Fume Hood |
| Lining : | Chemical & Heat Resistant ,Fire Retardant .Smooth Finish .Easily cleanable panels made of durable phenolic integral work walls (5mm thick ) |
| Sash Openning | 0-800 mm. |
| Average face velocity: | 0.5m/s |
| Front Top Panel: | Easily openable hinged top panel for easy access to Flow Control Valve and Electrical Lighting fixtures for maintenance . |
| Work Top : | 12.7mm phenolic top with double thicked edges ,15mm epoxy resin worktop ,30mm ceramic worktop ,30mm granite worktop |
| Windows Glass : | 5mm toughened glass |
| Light: | 20W xl >at least 400 LUX |
| Exhaust duct: | glass steel tube of PVC tube .corrosion resistance |
| Base : | SS304 |
| Socket: | 1.5amp switch with three sockets |
| Technical data : | noise < 60 dB (international):wind speed three-section exhaust |
