PHARMA fan filter unit inquire now for cosmetic factory
After Warranty Service: Video technical support, Online support, Field maintenance and repair service
Certification: CE ISO GMP
Name: Cleanroom swing door
Usage: cleanroom
Filter efficiency: 99.99%
Frame: Galvanized steel/Stainless steel
Limit Discounts
Description
The fan filter unit is one of the quietest and best-priced units on the clean market. With this unit, high quality air can be delivered to the clean room. And the air flow shape is good, it is suitable for semiconductor, electronic, flat panel display and disk drive manufacturers and optical, bio-industry and other industries in clean rooms, clean benches, clean production lines, assembly clean rooms and other places where there is strict control of air pollution. Low energy consumption and reduced operating costs.
Characteristics The unit appearance is simple and generous. Equipped with high qualit, high efficiency and low noise outer rotor backward inclined centrifugal blower. With stable and multi velocity regulation function. With functions perfect large scale group control operating system. |
Technical Parameters
| Model | FFU-2*2 | FFU-2*4 | FFU-4*4 | |
| Module sizeW×L×H(mm) | 575*575*250 | 1175*575*250 | 1175*1175*250 | |
| Air flow(m3/h) | 900 | 1000 | 1200 | |
| Average velocity(m/s) | 0.3-0.5 | |||
| Pressure(pa) | 97(10mmAq) | |||
| Power(W) | 100 | 175 | 250 | |
| Weight(kg) | 27.5 | 34 | 45.5 | |
| Noise dB | 52 | |||
| HEPA Filter | Size | 610*610*70mm | 1170*570*70mm | 1170*1170*70mm |
| Efficiency | 99.99% @0.3μm | |||
| Frame | High-quality aluminum | |||
| Pressure | 180pa 0.45m/s | |||
Installation
