PHARMA air shower clean room inquire now for chemical plant

Supply Ability:
50-100 Sets/per month
Start Port:
Shanghai
Size:
Customize
Price:
USD 3000-5000/Sets
Payment:
T/T; Cash; Alibaba trade assurance
Packing Details:
Carton packing, metal frame; plywood case
Original:
Suzhou, China
Model:
PH-1300-P1
Delivery Time:
15-20 days,depending on the quantity
Inquiry


  • After Warranty Service: Video technical support, Online support

  • Certification: CE ISO GMP

  • Name: Cleanroom air shower

  • Application: Pharmacy, medical, food industry

  • Blowing: Top, side blowing

  • Used: Hospital: Laboratory; Food workshop

  • Door: 5mm Glass

  • Material: Stainless steel 304/316, painted steel

  • Showering time: 0-99s

  • Size: Customize as client request


PHARMA air shower clean room inquire now for chemical plant 11


Limit Discounts

Limit Discounts


PHARMA air shower clean room inquire now for chemical plant 12


Description

Description


This is a kind of local purifying equipment, fixed on the partition between clean room and unclean room. It is used for shower and removing dust when personnel or objects entering into clean area. Effectively reduce dust source from entering into clean area after used, and keep clean area in normal working state. Shower way: single-side shower, double-side shower, three-side shower, top shower.

Air shower is widely used in LCD and Optoelectronic Display, PCB, microelectronics, dust-free coating, aseptic packaging, medical care, Pharmacy,auto glass and precision parts.


PHARMA air shower clean room inquire now for chemical plant 13
Characteristics

1. Photoelectric control, automatic shower.

2. Circulated air design keeps shower area clean in non-shower state.

3. Double doors adopt electric interlocking to force shower; double doors may be made as automatic movable door.

4. Made as negative pressure and anti-exploding air shower according to users' requirement.

5. Equipped with the device to remove static

6. Carry on air brake, cushion type and other particular design, manufacturing.

Technical Parameters

Technical Parameters


ModelPH-1300-P1PH-1300-P1PH-1300-P2PH-1300-P3
External dimension W×D×H(mm)1300×1000×21001300×1500×21001300×2000×21001300×3000×2100
Internal Dimensions W×D×H(mm)800×930×1960800×1430×1960800×930×1960800×930×1960
Speed25~27 (m/s)
Nozzle No.12 pieces18 pieces24 pieces36 pieces
StructureCabin: Pre-painted cold work steel sheet; Stainless steel 304
Door:  5mm glass and built-in automatic door closer
LightingLED, built-in type
Dust Collection EfficiencyOver 99.99% 0.3μm D.O.P TEST
HEPA Dimension ×Quantity595×595×80×2pcs595×595×80×2pcs595×595×80×4pcs595×595×80×4pcs
Showering Time0-99s adjustable(FACTORY SETTING 10S)
Power Supply380V 50Hz, 3Phase/220V 60Hz 1Phase

Installation

Installation


PHARMA air shower clean room inquire now for chemical plant 14

PHARMA air shower clean room inquire now for chemical plant 15


PHARMA air shower clean room inquire now for chemical plant 16


PHARMA air shower clean room inquire now for chemical plant 17


PHARMA air shower clean room inquire now for chemical plant 18

PHARMA air shower clean room inquire now for chemical plant 19

PHARMA air shower clean room inquire now for chemical plant 20


PHARMA air shower clean room inquire now for chemical plant 21
