nice air shower check now for herbal factory
After Warranty Service: Video technical support, Online support
Used: GMP clean room; Changing Room: Clean Booth
Size: Customize as client request
Application: Pharmacy, medical, food industry
Blowing: Top, side blowing
Certification: CE ISO GMP
Name: Air shower room
Door: 5mm Glass
Material: Stainless steel 304/316, painted steel
Showering time: 0-99s
Limit Discounts
Description
Air shower are specialized anti-chambers through which personnel must pass before entering cleanrooms in order to avoid contamination. Decontamination is done by clearing off dust and dirt particles from cargo of cleanroom to minimize contamination of equipment or products.
It is used to blow away dust on clothing, equipments, materials and tools before workers or objects enter the Clean Room; meanwhile, its Air Lock function may effectively control personnel passing in and out, as well as act as various levels of buffer room for clean room to prevent cross pollution.
Characteristics 1.Completely self-contained, Adjustable nozzles to remove surface contaminants. 2.Perfect for transferring personnel, carts and large equipment. 3.The cargo air shower room adopts a modular design, which can be assembled into various lengths of air shower according to actual needs. 4.Dual HEPA Filters remove 99.99% of particles > 0.3 Microns from the air stream. 5.Equipped with interlocking doors, automatically released when power fails. 6.Emergency Stop buttons on both doors immediately disengage interlocks and halt air shower. |
Technical Parameters
| Model | PH-ASC |
| Filter efficiency | ≥99.99%@0.3μm |
| Speed | ≥25 |
| Showering Time | 0-99 adjustable |
| Nozzle No. | 24 pieces |
| Internal Dimensions W×D×H(mm) | 1400*2000*2000mm |
| External dimension W×D×H(mm) | 1900*2100*2100mm |
| Structure | Cabin: Pre-painted cold work steel sheet; Stainless steel 304 |
| Door: 5mm glass and built-in automatic door closer | |
| Power Supply | 380V 50Hz, 3Phase/220V 60Hz 1Phase |
| Pre Filter Dimension ×Quantity | 650x400x15x3 piece |
| HEPA Dimension ×Quantity | 610x610x69x3 piece |
