hot-sale laboratory furniture wholesale for pharmaceutical
1. Defect-free PHARMA lab fume hood adopts high quality raw materials.
2. The daily development habits of SUZHOU PHARMA MACHINERY CO.,LTD. helps it produce the top-notch quality laboratory furniture .
3. Professional staff strictly check, to ensure that products always maintain the highest quality.
After Warranty Service: Video technical support, Online support, Field maintenance and repair service
Certification: CE ISO GMP
Name: Weighing Booth
Size: : 1600*3000*2600mm
Used: Clean room
Limit Discounts
Description
Weighing booth is a dedicated purification equipment for sampling, weighing and analysis. It can contain powders andparticles within work area and prevent operator from inhaling them.
Characteristics The negative pressure weighing chamber is composed of several parts of the working area, return air box body, air box body, air box body and outer box body. The control panel is located on the front of the working area inside the equipment. The control panel uses a light-touch LED control panel to control the start and stop of the fan, adjust the working conditions of the fan, and adjust the wind speed required in the work area. ). There is a differential pressure meter next to it, the resistance of the test filter is also inside the air supply box and there is an exhaust adjustment board, which can adjust the exhaust volume of the equipment within a reasonable range (after the equipment is installed in place, it is set by a professional Try, please do not adjust without permission) |
Technical Parameters
| Model | PH-W series |
| Internal Size (W*D*H) | 1600*3000*2600 12000*3000*2600 I 2500*3000*2600 |
| External Size (W*D*H) | 1500*2400*2000 1900*2400*2000 2500*2400*2000 |
| Class/Air Flow | SO5 0.45±20%m/s |
| Pre-filter | G4 (90%@5um) |
| Med-filter | F8 (85%~95%@1~5um) |
| HEPA filter | H14(99.995-99.999%@0.3) |
| Power Supply | 38OV/30/5OHz(Advice if different) |
| Control Mode | VFD Control/Simens PLC Control |
| Rated Power | 3kW 4kW 5kW |
| Total/Exhaust Volume | 8000/800(m3/h) 110000/1000(m3/h) | 13000/1300 |
| UV Light | Optional |
| Light Intensity | 2300Lx |
| Nose | M70dB (A) |
| Different Pressure Gauge(3 nos.) | 0-60Pa/0-250Pa/0-500Pa |
| Socket | P66/Qty.4 |
| MOC | SUS304/1.2mm |
